The Blackmagic Design ATEM Mini Pro is a compact, portable live production switcher designed for content creators, streamers, and producers. It offers 4 HDMI inputs, USB webcam output, and advanced streaming capabilities, making it ideal for multi-camera live productions. Its user-friendly interface and robust features enable seamless switching, transitions, and audio mixing, perfect for YouTube, Twitch, and professional broadcasts.
1.1 Overview of ATEM Mini Pro Features
The ATEM Mini Pro features 4 HDMI inputs for connecting cameras and devices, a USB webcam output for streaming, and a built-in audio mixer with Fairlight EQ. It supports direct recording to USB disks and streaming via Ethernet or USB-C. The device also includes a 2D DVE for picture-in-picture, multiview for monitoring inputs, and a media pool for graphics and titles. These features make it ideal for live production and streaming workflows.
1.2 Importance of the ATEM Mini Pro Manual
The ATEM Mini Pro manual is essential for unlocking its full potential, providing detailed setup guides, feature explanations, and troubleshooting tips. It helps users navigate advanced functions like ISO recording, audio mixing, and streaming configurations, ensuring optimal performance. The manual is a comprehensive resource for both beginners and professionals, offering step-by-step instructions and technical specifications to enhance live production workflows.
Key Features of ATEM Mini Pro
The ATEM Mini Pro features 4 HDMI inputs, USB webcam output, and a built-in audio mixer with Fairlight Audio. It supports multiview, streaming, and direct USB recording.
2.1 4 HDMI Inputs and USB Webcam Output
The ATEM Mini Pro’s 4 HDMI inputs allow connection of up to four video sources, such as cameras or gaming consoles. The USB webcam output enables direct integration with computers, making it ideal for streaming. This feature simplifies live production by allowing the switcher to appear as a webcam in software like Zoom or OBS, enhancing virtual meetings and broadcasts.
2.2 Built-in Audio Mixer and Fairlight Audio
The ATEM Mini Pro features a built-in Fairlight audio mixer, offering professional-grade sound control. Users can adjust levels, EQ, and balance for up to four HDMI sources and two dedicated audio inputs. This ensures high-quality audio integration, eliminating the need for external mixers. The Fairlight system provides precise control over audio sources, delivering clear and balanced sound for live streams and broadcasts.
2.3 Multiview and Streaming Capabilities
The ATEM Mini Pro includes advanced multiview functionality, allowing users to monitor all inputs and program outputs simultaneously. This feature enhances production efficiency by providing real-time feedback. Additionally, the device supports direct streaming via Ethernet or USB-C, enabling high-quality live broadcasts to platforms like YouTube and Twitch without requiring additional hardware or software.
System Requirements and Compatibility
The ATEM Mini Pro supports Windows 10 (64-bit) and macOS (10.14 Mojave or later). It requires a 12V power supply and is compatible with USB-C and Ethernet connectivity for streaming.
3.1 Supported Operating Systems
The ATEM Mini Pro is compatible with Windows 10 (64-bit) and macOS systems, specifically macOS 10.14 Mojave or later. This ensures seamless integration with popular streaming and editing software, making it versatile for both PC and Mac users. The device’s compatibility extends across various platforms, allowing creators to streamline their workflows without OS-related constraints.
3.2 Power and Technical Specifications
The ATEM Mini Pro operates with an external 12V power supply, consuming approximately 30W of power. It supports video formats up to 1080p60 and features a compact, lightweight design for portability. The device includes HDMI, USB-C, and Ethernet connectivity, ensuring reliable performance for live productions and streaming applications.
Setting Up the ATEM Mini Pro
Connect HDMI inputs to your cameras and external devices, then link via Ethernet for streaming. Configure settings using the ATEM Software Control for a seamless setup experience.
4.1 Connecting HDMI Inputs and Outputs
To connect devices to the ATEM Mini Pro, plug your cameras or sources into the HDMI inputs. Use the HDMI output to connect to a monitor or external recorder. Ensure all devices are powered on before connecting. The HDMI inputs automatically detect and configure the signal, while the output provides a live preview of your program feed for monitoring.
4.2 Configuring Audio and USB Outputs
Connect audio sources to the ATEM Mini Pro using the 3.5mm inputs or embed audio via HDMI. Adjust levels using the Fairlight audio mixer to ensure balanced sound. For USB output, connect to a computer to use the ATEM Mini Pro as a webcam. Configure the USB settings in the control software for streaming or recording; This setup enables high-quality audio and video integration for live broadcasts and productions.
Using the Audio Mixer
The Fairlight audio mixer in the ATEM Mini Pro allows precise control over audio levels, EQ, and mixing. Easily adjust input levels, apply equalization, and manage audio sources for optimal sound quality during live productions.
5.1 Adjusting Levels and EQ Settings
Adjusting audio levels and EQ settings in the ATEM Mini Pro ensures professional-quality sound. Use the Fairlight mixer to fine-tune input levels, apply high/low pass filters, and boost or cut frequencies to eliminate hum or enhance clarity. Real-time adjustments are visible on the mixer interface, allowing precise control to achieve balanced and polished audio for live streams or recordings.
5.2 Managing Audio Sources and Outputs
The ATEM Mini Pro allows seamless management of audio sources and outputs. Connect external microphones or instruments via the 1/8″ TRS inputs, and mix them with embedded HDMI audio. Use the Fairlight mixer to route audio sources to USB-C or HDMI outputs. You can also synchronize audio with video inputs and adjust channel levels independently for a balanced mix, ensuring professional-grade sound in live productions and recordings.
Transitions and Effects
The ATEM Mini Pro offers a variety of built-in transition effects, including dissolve, wipe, and DVE animations. Use the 2D DVE for dynamic picture-in-picture setups and green screen chroma keying, enhancing production value with professional-grade visual effects easily controlled via ATEM Software Control.
6.1 Built-in Transition Effects
The ATEM Mini Pro features a range of built-in transition effects, including dissolve, wipe, slide, and more. These effects enable smooth and professional switches between video sources. Users can easily customize transition duration and style using ATEM Software Control, ensuring seamless and polished live productions. The transitions are GPU-accelerated for real-time performance without latency or dropped frames.
6.2 Using the 2D DVE for Picture-in-Picture
The ATEM Mini Pro’s 2D DVE (Digital Video Effects) allows users to create customizable Picture-in-Picture (PiP) layouts. Adjust size, position, and borders to overlay video sources. Use masking tools to refine shapes and enable transparency for seamless overlays. This feature enhances live productions by adding depth and visual interest, making it ideal for interviews, live events, and multi-camera setups.
Media Pool and Graphics
The ATEM Mini Pro’s Media Pool enables easy upload and management of still images, titles, and graphics. Perfect for enhancing live productions with overlays and visual elements.
7.1 Uploading and Managing Still Images
Upload still images to the ATEM Mini Pro’s Media Pool via USB or software. Supports PNG, JPG, and BMP formats. Organize images for quick access during live production. Easily manage and preview stored graphics using the ATEM Software Control Panel. Ensure images are properly formatted for seamless integration into your live stream or broadcast. This feature enhances your production with professional-looking titles and overlays.
7.2 Adding Titles and Overlays
Easily add professional-looking titles and overlays to your production using the ATEM Mini Pro. Upload pre-designed graphics to the Media Pool and apply them during live switching. Access titles via the ATEM Software Control Panel, ensuring seamless integration. Overlays can include logos, watermarks, or custom text, enhancing your broadcast’s visual appeal. This feature allows for dynamic, real-time adjustments, making your content stand out with polished, professional presentation.
Recording and Streaming
The ATEM Mini Pro offers direct recording to USB disks for high-quality video storage and streams via Ethernet or USB-C for live online broadcasts effortlessly.
8.1 Direct Recording to USB Disks
Direct recording to USB disks on the ATEM Mini Pro allows for high-quality video storage without needing external equipment. Simply connect a USB disk to the designated port and enable recording via the ATEM Software Control or front panel. This feature ensures reliable backups and quick access to your content for post-production. The process is seamless and integrates perfectly with streaming workflows.
8.2 Streaming via Ethernet or USB-C
Streaming via Ethernet or USB-C on the ATEM Mini Pro enables high-quality live broadcasts to platforms like YouTube, Twitch, and Facebook. Ethernet provides a stable connection for streaming, while USB-C supports mobile internet sharing. Using the ATEM Software Control, users can easily configure streaming settings, including RTMP destinations, ensuring professional-grade live production without additional hardware. This feature simplifies real-time content delivery to global audiences.
Advanced Features
The ATEM Mini Pro includes advanced features like ISO recording for multi-camera editing, DaVinci Resolve integration, and Blackmagic Cloud support, enhancing collaborative and professional workflows seamlessly.
9.1 ISO Recording for Multi-Camera Editing
ATEM Mini Pro’s ISO recording captures all inputs as separate files, enabling flexible editing in post-production. This feature is ideal for multi-camera setups, allowing editors to easily sync and adjust each angle individually. By saving each input with matching timecode, it simplifies the relinking process in DaVinci Resolve, streamlining collaborative workflows for professional results.
9.2 Integration with Blackmagic Cloud
ATEM Mini Pro seamlessly integrates with Blackmagic Cloud, enabling real-time collaboration and media sharing; This feature allows automatic syncing of recorded files, making it easy for editors and designers worldwide to access content. The cloud integration streamlines post-production workflows, ensuring efficient project management and distribution. It complements ISO recording, enhancing teamwork and productivity for professional-grade content creation.
Troubleshooting Common Issues
Common issues with ATEM Mini Pro include connection problems and audio/video sync delays. Check HDMI cables, restart the device, and ensure software is updated for optimal performance.
10.1 Resolving Connection Problems
Connection issues with the ATEM Mini Pro often stem from faulty HDMI cables or incorrect settings. Ensure all HDMI inputs are securely connected and compatible. Restart the device and check the ATEM Software Control for input detection. If problems persist, update the firmware or reset the switcher to factory settings for troubleshooting.
10.2 Fixing Audio and Video Sync Issues
Audio and video sync issues can occur due to mismatched settings or delays. Check the Fairlight audio mixer settings and ensure all inputs are properly configured. Adjust the audio delay in the ATEM Software Control to align with video signals. Restart the device and verify HDMI connections. If issues persist, restore default settings or update the firmware for optimal performance.
The ATEM Mini Pro empowers creators with professional-grade live production tools. Its ease of use, combined with Blackmagic Design’s comprehensive support, makes it indispensable for streamers and producers alike.
11.1 Summary of Key Takeaways
The ATEM Mini Pro is a powerful, portable switcher with 4 HDMI inputs, USB webcam output, and advanced streaming features. It supports multi-camera productions, audio mixing, and direct recording. Its user-friendly design and compatibility with Blackmagic software make it ideal for streamers, YouTubers, and event producers. The device integrates seamlessly with DaVinci Resolve for post-production, offering a professional-grade solution for content creation. The comprehensive manual provides detailed guidance for mastering its features.
11.2 Next Steps for Mastering ATEM Mini Pro
After familiarizing yourself with the ATEM Mini Pro, explore advanced features like ISO recording and Blackmagic Cloud integration. Practice using the ATEM Software Control Panel for custom setups. Experiment with DaVinci Resolve for post-production workflows. Regularly update firmware and stay informed about new features. Join forums and tutorials to refine your skills. Mastering these steps will elevate your live production capabilities and unlock the full potential of the ATEM Mini Pro.
